This guide describes the production deployment architecture for the Onelink fork. Operationally, Onelink still inherits the same core infrastructure shape as Chatwoot, so this page should be treated as the base deployment architecture for the forked product.

​
Architecture

Running Onelink in production requires the following set of services.
  • Onelink web servers
  • Onelink workers
  • PostgreSQL Database
  • Redis Database
  • Email service (SMTP servers / SendGrid / Mailgun etc)
  • Object Storage (S3, Azure Storage, GCS, etc)
architecture Because Onelink is a fork of Chatwoot, updates can come from two directions:
  • upstream Chatwoot releases
  • fork-specific Onelink changes
Use the upstream sync strategy in the development docs when pulling changes from Chatwoot, and validate shared platform behavior plus domain profiles before promoting an update to the main branch. We recommend staying current with upstream security fixes and critical infrastructure improvements while keeping product-specific divergences intentional and documented. The deployment process for a newer version involves updating your app servers and workers with the latest code. Most updates would involve database migrations as well which can be executed through the following Rails command.
bundle exec rails db:migrate
The detailed instructions can be found in respective deployment guides.

​
Available deployment options

If you want to self-host Onelink, the recommended approach is to use one of the supported deployment paths below. Most of these documents are inherited from Chatwoot and remain relevant for the fork.

​
